Name：
-
Description：Main technical parameters name parameter unit jd5161hbt21 jd5161hbt28 jd5161hbt37 conveying capacity max.output m3 / h 50..
Product Details
| 主要指标参数the Main technical parameters | |||||
| 名称参数 | 单位 | JD5161HBT21 | JD5161HBT28 | JD5161HBT37 | |
| 输送量 Max.output | M3/h | 50 | 60 | 60-80 | |
| 混凝土出口压力 Max.pressure of concrete outlet | Mpa | 13/7.6 | 13/7.6 | 13/7.6 | |
| 额定工作压力 Rated working voltage | Mpa | 31.5 | 31.5 | 31.5 | |
| 泵送频率 Pumping frequency | times/min | 16/25 | 23/28 | 23/28 | |
| 料斗容积 Hopper volume | M3 | 0.6 | 0.6 | 0.6 | |
| 上料高度 Feeding height | mm | 1450 | 1500 | 1500 | |
| 液压系统型式 Hydraulic system mode | - | 开式open | 开式open | 开式open | |
| 分配阀行式 Transfer type | - | S管阀S-valve | S管阀S-valve | S管阀S-valve | |
| 油缸缸径 Cylinder diameter | mm | Φ125 | Φ125 | Φ125 | |
| 混凝土缸径 Concrete cylinder diameter | mm | Φ200 | Φ200 | Φ230 | |
| 液压油冷却 Oil pressure cooling way | 风冷 Air cooling | ||||
| 泵车臂架 Pump truck boom | |||||
| 布料高度 Max .placing height | m | 21 | 29 | 37 | |
| 回转角度 Rotation angle | ° | 540 | 540 | 540 | |
| 展臂角度 Elevation angle | ° | 90°/180°/360° | 90°/180°/360°/540° | 90°/180°/360°/720° | |
| 臂节数量 The number of boom | 节 | 3 | 4 | 5 | |
| 底盘及整车 Chassis and vehicle | |||||
| 底盘型号 Chassis mode | 东风 dongfeng | 豪沃/陕汽HOWO/SHANQI | |||
| 轴距 Wheel base | mm | 4700 | 4700/5200 | 5200 | |
| 发动机功率 Motor power | Kw | 160 | 195 | 228 | |
| 排放标准 Emission standard | 国VI | 国VI | 国VI | ||
| 整车质量 Overall weight | kg | 15995 | 18300 | 21000 | |
| 整车外型尺寸（L*W*H） Overall dimensions:LxWxH | mm | 9570*2350*3230 | 9900/2350/3650 | 10400/2480/3550 | |
| 其他 Other | |||||
| 液压油箱容积 Oil tank | L | 450 | 500 | ||
| 水箱容量 Water tank | L | 300 | |||
| 润滑方式 Lubrication mode | 集中自动润滑Centralized lubrication | ||||
| 控制方式 Control mode | 手动+无线遥控 Manual+radio | ||||
| 主液压元件 Main hydraulic component | lmported | ||||
