48m pump truck
48m pump truck
  • Name:

    48m pump truck

  • Description:
    Electronic control system the electrical system has a high degree of automation and strong. Schneider is used as the main..

Product Details

主要指标参数the Main technical parameters
输送量 Max.outputM3/h506060-80
混凝土出口压力 Max.pressure of concrete outletMpa13/7.613/7.613/7.6
额定工作压力 Rated working voltageMpa31.531.531.5
泵送频率 Pumping frequencytimes/min16/2523/2823/28
料斗容积 Hopper volumeM30.60.60.6
上料高度 Feeding heightmm145015001500
液压系统型式 Hydraulic system mode-开式open开式open开式open
分配阀行式 Transfer type-S管阀S-valveS管阀S-valveS管阀S-valve
油缸缸径 Cylinder diametermmΦ125Φ125Φ125
混凝土缸径 Concrete cylinder diametermmΦ200Φ200Φ230
液压油冷却 Oil pressure cooling way
风冷    Air cooling
泵车臂架  Pump truck boom
布料高度 Max .placing heightm485256
回转角度 Rotation angle°540540540
展臂角度 Elevation angle°90°/180°/360°90°/180°/360°/540°90°/180°/360°/720°
臂节数量 The number of boom345
底盘及整车 Chassis and vehicle
底盘型号 Chassis mode
东风 dongfeng豪沃/陕汽HOWO/SHANQI
轴距 Wheel basemm47004700/52005200
发动机功率 Motor powerKw160195228
排放标准 Emission standard
其他 Other
液压油箱容积 Oil tankL450500
水箱容量 Water tankL300
润滑方式 Lubrication mode
      集中自动润滑Centralized  lubrication
控制方式 Control mode
手动+无线遥控     Manual+radio
主液压元件 Main hydraulic component
