Power Elbow Tee

Name：

Manual Placing boom
Description：

The product structure of Jeddah heavy industry's new drum manual distributor: it generally adopts channel steel or round ..

Product Details

手动布料机01

手动布料机02

The product structure of Jeddah heavy industry's new drum manual distributor: it generally adopts channel steel or round pipe structure, boom, standard bearing, conveying pipeline, adding large counterweight box, etc., which enhances the stability and stability of the equipment. The 360 ° full rotation boom structure is adopted. The whole machine has the characteristics of simple operation, flexible rotation, energy saving, economy and practicality.

手动布料机主要技术参数 Main Technical Parameters of Manual Distributor
型号 Model	布料半径(m) Horizontal	布料高度(m) Cloth height	管径(mm） pipe diameter	回旋范围(°) Rotationange	整机质量(kg) Overallweight	配重(kg) Counterweiht
BLG-6m	6	0.5	Φ125	360	700	350
BLG-8m	8	0.5	Φ125	360	800	400
BLG-10m	10	0.5	Φ125	360	1100	900
BLG-12m	12	3.5	Φ125	360	1200	1000
BLG-15m	15	3.5	Φ125	360	1500	1200
BLG-18m	18	3.5	Φ125	360	2500	1600
BLG-20m	20	3.5	Φ125	360	3000	1800
